Print Method
Thermal Transfer / Direct Thermal |
Resolution
203 dpi (8 dots/mm) |
Print Speed
5 IPS (127 mm/s) |
Print Width
4.25" (108 mm) |
Print Length
Min. 0.16” (4 mm)**; Max. 68” (1727 mm) |
| |
Memory
8MB Flash (4MB for user storage) / 16MB SDRAM |
| |
Sensor Type
Fixed transmissive sensor and movable reflective sensor |
| |
Media
 Types: Continuous form, gap labels, black mark sensing, and punched hole; label length set by auto sensing or programming
Width: 0.79” (20 mm) – 4.64” (118 mm)
Thickness: 0.003” (0.06 mm) Min. - 0.01” (0.2 mm) Max.
Label roll diameter: Max. 5” (127 mm)
Core diameter: 1”, 1.5” (25.4 mm, 38.1 mm) |
| |
Ribbon
Types: Wax, wax/resin, resin
Length: 981" (300 m)
Width: 1.18” Min - 4.33” (30 mm - 110 mm) Max
Ribbon roll diameter.: 2.67“ (68 mm)
Core diameter: 1” (25.4 mm) |
| |
Printer Language
EZPL, GEPL, GZPL auto switch |
| |
Software
Label design software: GoLabel (for EZPL only)
Driver & DLL: Windows 2000, XP, Vista, 7,8, Windows Server 2003 & 2008 |
| |
Resident Fonts
Bitmap fonts 6, 8, 10, 12, 14, 18, 24, 30, 16X26 and OCR A & B
Bitmap fonts 90°, 180°, 270° rotatable, single characters 90°, 180°, 270° rotatable
Bitmap fonts 8 times expandable in horizontal and vertical directions
Scalable fonts 90°, 180°, 270° rotatable |
| |
|
Download Fonts
Bitmap fonts 90°, 180°, 270° rotatable, single characters 90°, 180°, 270° rotatable
Asian fonts 90°, 180°, 270° rotatable and 8 times expandable in horizontal and vertical directions
Scalable fonts 90°, 180°, 270° rotatable
|
| |
Barcodes
1-D Bar codes: |
| Code 39, Code 93, EAN 8 /13 (add on 2 & 5), UPC A/E (add on 2 & 5), I 2 of 5 & I 2 of 5 with Shipping Bearer Bars, Codabar, Code 128 (subset A, B, C), EAN 128, RPS 128, UCC 128, UCC/EAN-128 K-Mart, Random Weight, Post NET, ITF 14, China Postal Code, HIBC, MSI, Plessey, Telepen, FIM, GS1 DataBar |
| 2-D Bar codes: |
| PDF417, Datamatrix code, MaxiCode, QR code, Micro PDF417, Micro QR code, Aztec code |
Code Pages
CODEPAGE 437, 850, 851, 852, 855, 857, 860, 861, 862, 863, 865, 866, 869, 737
WINDOWS 1250, 1251, 1252, 1253, 1254, 1255 |
| |
Graphics
Resident graphic file types are BMP and PCX, other graphic formats are downloadable from the software |
| |
Interfaces
USB 2.0, Ethernet 10/100 Mps, RS-232 |
| |
Control Panel
Two dual color LEDs (Ready & Status)
Control key: FEED
Power on/off button
Calibration button |
| |
Power
Auto Switching 100-240VAC, 50-60Hz |
| |
Environment
Operation temperature: 41°F to 104°F (5°C to 40°C)
Storage temperature: -4°F to 122°F (-20°C to 50°C) |
| |
Humidity
Operation: 30-85%, non-condensing.
Storage: 10-90%, non-condensing. |
| |
Agency Approvals
CE(EMC), FCC Class A, CB, CCC, cUL |
| |
Dimension
Length: 11” (280 mm)
Height: 7.3” (186 mm)
Width: 8.3” (210 mm) |
| |
Weight
6.6 lbs (3Kg) ,excluding consumables |
| |
Options
USB Device + Parallel interfaces (factory install)
Guillotine Cutter
Label Dispenser
External label roll holder for 10” (250 mm) O.D. label rolls
External label rewinder |
|
